Description
Product manual
Lefedi power surge protector refers to the national standard GB/T18802.21-2004/IEC61643-21:2000 to design DC power surge protector, specially used for DC power surge protection, it adopts series protection mode, built-in overcurrent The overvoltage suppression unit makes the protected DC power supply safer and work stably. DC power surge protectors are divided into four specifications: 12V, 24V, and 220V, corresponding to different voltages, to protect the power supply.
Product advantages
◆ Installed at the power port of the equipment, used for lightning protection and anti-surge protection of power lines
◆ 3 voltage levels 12V, 24V, 220V, to meet different power equipment;
◆ Series installation, lower residual voltage, load current 10A;
◆ Temperature control protection, immediately interrupt the power line after the product fails.
Technical Parameters
model | LFD-DP/12 | LFD-DP/24 | LFD-DP/220 |
Features | power supply | power supply | power supply |
Nominal working voltage UN | DC12V/DC5V | AC24V | AC220V |
Maximum continuous operating voltage Uc | 30V | 30V | 285V |
Nominal load current IL | 2A | 2A | 2A |
Nominal discharge current (8/20μS)In | 5KA | ||
Maximum discharge current (8/20μS)Imax | 10KA | ||
Voltage protection level (In)Up | ≤60V | ≤90V | ≤900V |
Response time Ta | ≤25ns | ≤25ns | ≤25ns |
Insertion loss Ae | ≤0.3db | ≤0.3db | ≤0.3db |
Interface Type | Terminals | Terminals | Terminals |
Installation specifications | 1.5-4mm2 | 1.5-4mm2 | 1.5-4mm2 |
Dimensions | 90*61*18mm | ||
Shell material | PBT Flame retardant plastic,UL94-V0 | ||
temperature range | -40℃…+85℃ |
